Pierce® CP600 Center Pivot Irrigation System – 1,300 FT Heavy-Duty Farm Pivot

🚨 CALL FOR PRICING & AVAILABILITY 🚨

The Pierce® CP600 Center Pivot System is a premium heavy-duty irrigation system engineered for maximum water coverage, long service life, and dependable field performance. Built with galvanized spans, heavy-duty towers, and UMC® drivetrain components, this 1,300-foot center pivot is designed to handle demanding agricultural operations while delivering efficient and uniform irrigation.

Ideal for row crops, large farms, and high-acreage irrigation applications, the CP600 combines structural strength with advanced control technology for superior performance season after season.

Pierce® CP600 System Specifications

Pivot Point Assembly

• (1) CP Pivot Point Standard Profile Assembly
• (1) Inlet Elbow IF x CPF 8.63" x 8.63" Assembly
• (1) Anchor Bolt Kit

Advanced Pivot Controls

• (1) iControl® Standard Panel
  • Auto-Reverse
  • Auto-Stop
  • System Monitoring
  • Stainless Steel Enclosure
• (1) INS-8 Collector Ring (11-Conductor)

Spans, Towers & Overhang

• (1) 164.5' Span – 6-5/8" Galvanized Pipe
• (6) 184' Spans – 6-5/8" Galvanized Pipe
• 58.5" outlet spacing throughout system
• (6) Intermediate Towers
  • 9'6" Standard Profile
  • Heavy-Duty Construction
• (1) End Tower
  • 9'6" Standard Profile
  • Heavy-Duty Construction
• (1) 19.5' Overhang – 6-5/8" Pipe
• (7) Shielded Span Cables – 12 Gauge
• Standard Alignment System with (7) Tower Boxes

Drivetrain & Mechanical Components

• (7) 11.2 x 24 Tires
• Standard Profile Drivetrain – 50:1 Ratio
• (14) UMC® 740-U-AD Gearboxes
  • 50:1 Gear Ratio
  • Heavy-duty performance
• (7) UMC® Gearmotors
  • 43/36 RPM
  • 0.75 HP

Optional Equipment

✅ End Tower Run Light

Why Choose the Pierce® CP600 Pivot System?

• Designed for maximum irrigation coverage and water efficiency
• Heavy-duty galvanized spans and towers built for long life
• Premium UMC® drivetrain components for dependable operation
• Advanced iControl® pivot panel for easy monitoring and control
• Built for large acreage farms and demanding irrigation environments
• Engineered for strength, reliability, and long-term performance

🌾 Built Tough for Generations

👉 Call Today for Pricing & Availability
📞 Darrin Addison: 620-338-0894
